Shenzhen Risingstar Outdoor High Light LCD Co., Ltd
Shenzhen Risingstar Outdoor High Light LCD Co., Ltd
Min. Order:1 Piece/Pieces
Brand: Risingstar
famokarana: 135K
Toerana iraisana: Shenzhen
taratasy fanamarinana: CE/ROSH/UL/ISO9001
15.4Inch 1000 Nits Outdoor efijery avy amin'ny efijery Shenzhen Risingstar .Izany 15.4 "LCD Module miaraka amin'ny haingam-pandeha A-Si TFT-LCD, ao anatin'izany ny Sensor Lead Drive.with dia azo amboarina araka ny hazavana akaiky Ny loharanom-baovao dia miova.
Ny fakantsary hazavana LCD avo dia mila ora maro, ary ny fahasamihafan'ny tontolo iainana sy ny fiovan'ny mari-pana dia lehibe. Noho izany, ny mifanohitra amin'izany, ny faharetana sy ny fahitsiana dia lasa endri-javatra tsy takatry ny saina amin'ny efijery LCD indostrialy. 15.4 Ny tontolon'ny TFT LCD santimetatra dia mahafeno an'io filana io.
Ny famirapiratry ny tontolon'ny LCD Panel dia afaka mahatratra 350nits ihany, fa ny 15,4Inch 1000 NITS Outdoor TFT LCD dia mety hahatratra 1000 CD / M 2 , 1000nits , namaky ny tsanganana an-gazety, ny tsanganana fampisehoana an-tsehatra, sns.
| Product size | 15.4" | Type | a-Si TFT-LCD |
| Pixel Format | 1920(RGB)×1200[WUXGA] 147PPI | Configuration | RGB Vertical Stripe |
| Active Area | 330.62(H)×206.64(V) mm | Outline Dim. | 341.2(H)×219.14(V) ×13(D) mm |
| Viewing Angle | 80/80/70/70 (Min.)(CR≥10) | Treatment | Hard coating (3H) |
| Luminance | 800-1000 cd/m² (Typ.) | Contrast Ratio | 1450:1 (Typ.) (TM) |
| View Direction | Symmetry | Response Time | 10/8(Typ.)(Tr/Td) |
| Support Color | 16.2M 56% NTSC | Light Source | WLED ,20K hours , With LED Driver |
| Weight | 830/850g(Typ./Max) | Designed For | Outdoor High Brightness Automotive Display |
| Frequency | 60Hz | Touch Panel | Without |
| Interface Type | LVDS(1 ch,2 port) , 6pins | ||
| Power Supply | 12.0V (Typ.) | ||
| Environment | Operating Temperature: -40 ~ 95 °C ; Storage Temperature: -30 ~ 85 °C |
