Model No.: BA104S01-100
Ba104S01-100 dia vokatra 10,4-santimetatra LCD Module natolotry ny Teknolojia Boe Technology Group Co., Ltd. (Boe) mampiasa teknolojia TFT-LCD A-SI. Izy io dia fitaovana fanimbafana, tsy misy mpitondra lalana ary tsy hikasika. Ba104S01-100 dia mampiseho ny fanapaha-kevitra ny 800 (RGB) × 600 (SVGA), endrika iray amin'ny isa 4: 3 .1 Navoakan'i Boe tamin'ny 12 Desambra 2014. Ny haben'ny faritra dia ny 211.2 158.4 × 5.9 (matevina) mm, ny fitsaboana amin'ny tany dia mazava, ny lanjan'ny vokatra dia 288g (typ.). Manorata ity vokatra ity dia mampiasa loharanom-pidirana amin'ny lafiny 6s6p Adopts LVDS (1 C, 6/8-bit) Fambara famantarana, 1 Pins Ny tahan'ny famelomana mahazatra mahazatra FV dia 60hz. Izy io dia miasa amin'ny -20 ° C hatramin'ny 70 ° C sy ny fivarotana amin'ny -30 ° C ka hatramin'ny 80 ° C. Ity modely ity dia natokana ho fampiasa amin'ny indostrian'ny indostrian sy ny fitsaboana noho ny famaranana azy fotsy, maherin'ny 50 000 ora fiasana, terminal flip, 6/8 bitika ny marika fotsy volo, ary ny endri-javatra fotsy volo.
| brand | BOE | Model name | BA104S01-100 |
| size | 10.4 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 800(RGB)×600 [SVGA] 96PPI | Pixel configuration | RGB vertical bar |
| Display Area | 211.2×158.4 mm (H×V) | Surface treatment | Clear |
| Visual size | 215.0×162.0 mm (H×V) | Contrast Ratio | 800:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 236×176.9×5.9 mm (H×V×D) |
| Viewing Angle | 70/70/60/70 (Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 6/8-bit) ,erminal, 20 pins | ||
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
Ireto manaraka ireto dia mitovy habe sy tarehimarika mitovy
| brand | BOE | Model name | AV104X0M-N10 |
| size | 10.4 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768 (XGA) 123PPI | Pixel configuration | RGB vertical bar |
| Display Area | 210.4 × 157.8 (H×V) mm | Surface treatment | / |
| Visual size | 215.4 × 161.8 (H×V) mm | Contrast Ratio | 1100:1 (Typ.) (TM) |
| Brightness(cd/m²) | 600cd/m²(Typ.)or customized | Outline dimension | 230 × 180.2(H×V) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 6/8-bit) ,erminal, 20 pins | ||
| work environment | Storage temperature: -40 to 95 °C Operation Temperature: -30 to 85 °C |
| brand | BOE | Model name | TDA104-001V02 |
| size | 10.4 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768 (XGA) 123PPI | Pixel configuration | RGB vertical bar |
| Display Area | 210.4 × 157.8 (H×V) mm | Surface treatment | / |
| Visual size | / | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Brightness(cd/m²) | 900cd/m²(Typ.)or customized | Outline dimension | 235×173×10.5mm(H×V×D) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 8-bit) ,erminal, 20 pins | ||
| work environment | Storage temperature: -55 to 85 °C Operation Temperature: -40 to 80 °C |
Tags mafana: Boe Ba104S01-100 500nits TFt-LCD Panel, China, Factory, Vidiny, Screen, Screen, Windows, Screen Screen, efijery HD, Screen, 19inch LCD, 19inch LCD, LCD efijery ho an'ny ivelany , tontonana LCD, LCD Module, fampisehoana avo be.
