Model No.: LQ156M1LG21
Ny LQ156M1LG21 dia manana vahaolana apetraka amin'ny 1920 (RGB) × 1080 (FHD), endrika endrika amin'ny 16: 9
Ny haben'ny faritra misy ny haben'ny LQ156M1LG21 dia 344.16 × 193.59 (W × H) MM, ny habe hita dia 349.0 × 198.4 (W × H) MM, ny habe ivelany dia 370 × 217 (W × H) × 9.8 (D) MM, Famaranana ny fitsaboana ara-tsosialy, ny coating mafy (3h), lanja net 950g (max.)
Raha resaka fanodinana, ny loharano maivana maivana dia ampiasaina, ary ny fotoam-pivavahana amin'ny loharanom-pahazavana dia 50k ora. ° C.
| brand | Sharp | Model name | LQ156M1LG21 |
| size | 15.6inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1920(RGB)×1080 FHD | Pixel configuration | RGB vertical bar |
| Display Area | 344.16×193.59(H×V)mm | Surface treatment | Fog surface，Hard coating (3H) |
| Visual size | 349.0×198.4(H×V)mm | Contrast Ratio | 800:1 (Typ.) (TM) |
| Brightness(cd/m²) | 600cd/m²(Typ.)or customized | Outline dimension | 370×217×9.8(H*V*D) mm |
| Viewing Angle | 80/80/80/65 (Typ.)(CR≥10) | work environment | Storage temperature: 0 to 70 °C Operation Temperature: -30 to 70 °C |
| Signal interface | 30 pins LVDS (2 ch, 8-bit),erminal |
|
|
| supply voltage | 3.3V (Typ.) |
|
|
