Model No.: LQ150X1LW96
Ny fanapahana LQ150x1Lw96 dia ny 1024 (RGB) × 768 (XGA), ny lafiny iray dia 4: 3 Ny haben'ny fampisehoana ny haben'ny LQ150x1Lw96 dia 304.128 ×, ny habe hita maso dia 307.4 × 231.3 (W × H) MM, ary ny habe ivelany dia 326.5 (w) × 10.1 (D) MM. Famaranana matte, coating mafy (3h), lanja net 950g (max.)
Ny jiro dia manangana loharano maivana, ny mari-pana am-piasana dia -20 ~ 70 ° C, ary ny mari-pana ao aminy dia -25 ~ 70 ° C, izay mety amin'ny indostrian'ny indostria sy ny fitsaboana.
| brand | Sharp | Model name | LQ150X1LW96 |
| size | 15inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768 [XGA] 85PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.128×228.096mm(H×V) | Surface treatment | Fog surface，Hard coating (3H) |
| Visual size | 307.2×231.1mm(H×V) | Contrast Ratio | 1500:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 326.5×253.5×10.1(H×V×D)mm |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | work environment | Storage temperature: -25 to 70 °C Operation Temperature: -20 to 70 °C |
| Signal interface | LVDS (1 ch, 6/8-bit),erminal,20 pins | ||
| supply voltage | 3.3V (Typ.) |
Q: Ianao ve mpanamboatra (orinasa)?
A: Eny, izahay. Misy koa ny serivisy OEM / ODM misy eto ..Manana hizara ny hevitrao aminay. Fahafinaretana ny manome vahaolana tsara indrindra ho anao.
F: Afaka mividy santionany amin'ny baikoko ve aho?
A: Eny, azafady azafady mba hifandray aminay.
Tags mafana: LQ150x1Lw96 Sharp TFT LCD Lcd LVDS, China, Factory, Cheap, Screen, Screen, 49 semi outdoor, efijery Fampisehoana SEMI 1000nits lcd efijery
