Min. Order:1 Piece/Pieces
Brand: Risinglcd
famokarana: 1500K
Toerana iraisana: Shen zhen
taratasy fanamarinana: CE/ROSH/UL/ISO9001
| Panel Brand | RISINGSTAR | Panel Model | RS156XW-NE10 |
| Panel Size | 15.6" | Panel Type | a-Si TFT-LCD , LCM |
| Resolution | 1366(RGB)×768 (WXGA) 100PPI | Pixel Format | RGB Vertical Stripe |
| Display Area | 344.232 × 193.536 (H×V) | Surface | Antiglare, Hard coating (3H) |
| Outline Size | 363.8 × 215.9 × 17.35 (H×V×D) | Contrast Ratio | 500:1 (Typ.) (TM) |
| Brightness | 1000nit or customized | Display Mode | TN, Normally White, Transmissive |
| Viewing Angle | 85/85/80/80 (Typ.)(CR≥10) | Response Time | 6/2 (Typ.)(Tr/Td) ms |
| Display Colors | 16.2M 70% NTSC | Lamp Type | WLED , 50K hours , With LED Driver |
| Frequency | 60Hz | Input Voltage | 5V (Typ.) |
| Weight | 1.25/1.35Kgs (Typ./Max.) | Signal Interface | LVDS (1 ch, 8-bit) , Connector 30 pins |
| Environment | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 60 °C | ||
1. Ny fivoaran'ny fivoaran'ny hazavana avo lenta avo lenta
2.Propessional hazavana hazavana lcd avo lenta, dia mahazaka mari-pana 110
3.Samsung, LG, Beo, Auo, Innolux Coompersprises
4.Tsy manome ny fitarihana teknolojia matihanina matihanina
Tags mafana: 15,6 santimetatra ny efijery, China, Factory, Cheap, vidiny, fiakarana, fikolokoloana lcd, efijery 15 1 santimetatra , TV LCD Panel , tontonana LCD, LCD Module, fampisehoana hazavana avo.
17 "1500nit outdoor touch efijery
15,6 santimetatra 1000nit outdoor lcd fampisehoana
