Brand: Risinglcd
famokarana: 160K
Toerana iraisana: Shen zhen
taratasy fanamarinana: CE/ROSH/UL/ISO9001
| Panel Brand | RISINGSTAR | Panel Model | RS220WPM-NE10 |
| Panel Size | 22.0" | Panel Type | a-Si TFT-LCD , LCM |
| Resolution | 1680(RGB)×1050, WSXGA+, 90PPI | Pixel Format | RGB Vertical Stripe |
| Display Area | 473.76(W)×296.1(H) mm | Bezel Opening | 477.7(W)×300.1(H) mm |
| Outline Size | 493.7(W)×320.1(H) ×10.7(D) mm | Surface | Antiglare (Haze 25%), Hard coating(3H) |
| Brightness | 1000nit or customized | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 85/85/80/80 (Typ.)(CR≥10) | Display Mode | TN, Normally White, Transmissive |
| Display Colors | 16.7M 72% NTSC | Response Time | 1.5/3.5 (Typ.)(Tr/Td) |
| Frequency | 60Hz | Lamp Type | 3 strings WLED , 40K hours , Without Driver |
| Weight | 1.83Kgs (Typ.) | Input Voltage | 5.0V (Typ.) |
| Signal Interface | LVDS (2 ch, 8-bit) , 30 pins Connector | ||
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -25 ~ 60 °C | ||
RS220WPM-NE10 dia tara-masoandro 22 santimetatra azo vakiana amin'ny fampisehoana LCD izay manohana ny interface LVDS. Mety miasa amin'ny mari-pana avy amin'ny -20 ~ 70 ℃ sy ny mari-pana fitahirizana avy amin'ny -30 ~ 80 ℃. RS220WPM-NE10 dia 1000 Nits avo lccd maoderina TFT LCD. Mety amin'ny fitaovana indostrialy, fitaovana vita amin'ny tanana, fitaovana ara-pitsaboana, tontolo iainana ivelany ary semi-outdoor.
Toetoetra
1
2. Line famokarana matihanina nasionaly, tontolo iainana an-tapitrisany maro, ny vatan'ny efijery ary ny efijery fitantanana;
3. fanamarinana, FCC, CE, CCC, UL, Rohs;
4. Teknolojia LED LED LED LED.
5. firafitra mahery vaika, fiatraikany anti-ivelany, chassis metaly.
1. Mpanamboatra LCD Panel LCD matihanina matihanina
2. Ny efijery LCD-hazavana matihanina, dia afaka miatrika hafanana 110
3. Samsung, LG, Beo, Auo, Company mpiara-miasa Innolux
4. Manome anao amin'ny fifampidinihana ara-teknika sy fitarihana ara-teknika matihanina
F: Afaka mividy santionany amin'ny baikoko ve aho?
A: Eny, azafady azafady mba hifandray aminay.
F: Ahoana no ahafahantsika miantoka kalitao?
A: Fanadihadiana farany foana alohan'ny fandefasana;
F: Inona no tombontsoantsika?
A: Ny vokatra ambany ambany kalitao, fampahalalana ara-potoana ara-potoana.
F: Hafiriana ny warranty?
A: Manolotra antoka iray isan-taona izahay manomboka amin'ny datin'ny fanaterana.
F: Efa miasa na mpanamboatra ve ianao?
A: fa orinasa izahay.
