Model No.: MG4700S01-1
Brand: Risinglcd
famokarana: 220k
Toerana iraisana: CHINE
taratasy fanamarinana: CD/ROSH/ISO9001
Ny MG4700S01-1 dia manana vahaolana amin'ny 3840 (RGB) × 180, endrika iray amin'ny lafiny> 3: 1 Ny haben'ny fampisehoana dia 1192.3 × 55.89 (W × H) MM, ary ny haben'ny ivelany dia 1208.12 × 72.59 (W × h) MM. Ny mari-pana amin'ny fampandehanana ny MG4700S01-1 dia 0 ~ 50 ° C, ary ny mari-pana fitahirizana dia -20 ~ 60 ° C.
[Serivisy fijanonana iray, fandidiana eran-tany ary fanohanana eo an-toerana]
Ny Star Star dia manome ny mpanjifa amin'ny serivisy miantsena iray, ary ny vokatra dia nandalo fitsapana mafy mba hahazoana antoka fa mahafeno ny fepetra manokana ny kalitao; Ary manorata rafitra fitantanana kalitao tena ilaina araka ny fenitra iraisam-pirenena. Ny fandidiana maneran-tany, hanome ny consultik lafatra sy ny fanohanana ary ny serivisy ara-barotra.
| brand | CSOT | Model name | MG4700S01-1 |
| size | 47inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 3840(RGB)×180 81PPI | Pixel configuration | RGB vertical bar |
| Display Area | 1192.3×55.89(H×V)mm | Surface treatment | Fog surface(Haze 25%) |
| Visual size | / | Contrast Ratio | 3000:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 1208.12×72.59 (H×V)mm |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | work environment | Storage temperature: -20 to 60 °C Operation Temperature: 0 to 50 °C |
| Signal interface | V-by-One 8 lane,51 pins,erminal | ||
| supply voltage | 12.0V (Typ.) |
